AFPX C60TD PLC System About
Technical Specification
| Bandwidth | 10 Khz |
| Phase | Three Phase |
| Width | 124.6mm |
| Humidity | 95% |
| Model Name/Number | AFPX C60TD |
| Operation Temperature | 120 Deg C |
| Power | 220 V AC |
| Brand | Panasonic |
| Depth | 59.5mm |
| Operating Pressure | 200 Bar |
| Response Time | 5 ms |
| Mounting Type | PC Board |
| No Of Inputs | 9 Digits |
| Current | 0.1 A |
Advanced Performance and ConnectivityThe AFPX-C60TD PLC system delivers exceptional speed and flexibility for automation tasks. With its 32k steps of program memory and a scan time of 0.08 s per basic instruction, it accommodates complex sequences with efficiency. Integrated USB, RS232, and RS485 communication interfaces allow seamless connection with peripheral devices and programming tools, making it adaptable for diverse applications.
Expandable and Flexible ConfigurationDesigned for growth, the AFPX C60TD supports up to four expansion units, allowing you to scale I/O terminals as project requirements evolve. The systems configurable sink/source transistor outputs and DIN rail or panel mount options ensure flexible installation and adaptation to various industrial settings.
Reliability and Safety AssuredEquipped with built-in safeguards against overvoltage, overload, and short-circuit events, the AFPX-C60TD is engineered for long-term stability. Compliance with CE, UL, and cUL standards, plus operation in temperatures from 0C to 55C and high humidity conditions, ensures dependable service in even demanding factory environments.
FAQs of AFPX C60TD PLC System:
Q: How does the AFPX-C60TD PLC System benefit industrial automation projects?
A: The AFPX-C60TD offers high-speed processing, flexible I/O expansion, and robust protection features, making it ideal for controlling machinery, process lines, and building management systems. Its compact size and integrated communication ports enhance adaptability while the onboard LCD screen simplifies diagnostics.
Q: What types of outputs can the AFPX-C60TD handle, and are they configurable?
A: The AFPX-C60TD is equipped with 24 transistor outputs that can be configured as sink or source, allowing you to tailor output logic according to device requirements and application needs.
Q: When should I consider expanding the I/O on my PLC system?
A: Expansion should be considered when project requirements exceed the base 36 digital inputs and 24 outputs. The AFPX-C60TD allows up to four expansion units, supporting growth for more sophisticated automation tasks.
Q: Where can the AFPX-C60TD be installed, and what mounting options are available?
A: This PLC system supports both DIN rail and panel mounting, offering flexibility for use in control cabinets or machinery panels in factory, industrial, or building automation settings.
Q: How is programming and data communication managed with the AFPX-C60TD?
A: Programming is performed via the integrated USB port, while RS232 and RS485 interfaces allow for data communication with supervisory systems, HMIs, or other controllers. This ensures smooth integration into various automation networks.
Q: What safety features does the AFPX-C60TD offer during operation?
A: The system includes overvoltage, overload, and short-circuit protection, ensuring secure operation and safeguarding both the equipment and connected devices under demanding conditions.
Q: What is the operating temperature and humidity range for the AFPX-C60TD?
A: The AFPX-C60TD operates reliably at temperatures from 0C to 55C and in relative humidity ranging from 10% to 95% (non-condensing), making it suitable for a wide range of industrial environments in India.
