MEAN WELL LRS-50-15

Get a Price/Quote

MOQ : 1 Unit

MEAN WELL LRS-50-15 Specification

Connector Type
Screw terminal

Power Factor
0.5 at 230VAC

Operating Temperature
-30C~+70C

Rated Current
3.5A

Cooling Method
Convection

Output Current
0~3.5A

Noise Level
<50mV (Ripple & Noise)

Working Temperature
-30C~+70C

Phase
Single Phase

Application
Industrial control, factory automation, mechanical equipment, electrical devices

Rated Power
52.5W at 230VAC/50Hz

Output Type
Single

Current Range
0~3.5A

Power Supply
Switching Power Supply

Features
UL/cUL/IEC/EN62368-1 safety approved, compact size, low cost, high reliability, built-in EMI filter, LED indicator for power on

Product Type
AC-DC Single Output Enclosed Power Supply

Output Power
54W

Output Frequency
47~63Hz

Input Voltage
85~264VAC, 120~373VDC

Voltage Protection
Overvoltage, Overload, Short circuit protection

Efficiency
88%

Material
Metal (Enclosed) case

Line Regulation
0.5%

Storage Temperature
-40C~+85C

Weight
230g

Vibration Resistance
10~500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

Leakage Current
<0.75mA / 240VAC

Insulation Resistance
>100M / 500VDC

Humidity
20~90% RH (non-condensing)

Adjustment Range
13.5~16.5V (V. Adj. Range)

Surge Protection
Meets IEC61000-4-5

Output Voltage
15V DC

Safety Standard
UL62368-1, EN62368-1, IEC62368-1

Dimensions (L x W x H)
99 x 82 x 30mm

Mounting Type
Chassis Mount

Startup/hold up time
800ms, 30ms/230VAC (typ.)

MEAN WELL LRS-50-15 Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
7 Units Per Week

Delivery Time
7 Week

About MEAN WELL LRS-50-15

SPECIFICATION

Output Current	2A
Output Voltage	24 Vdc
Input Voltage	110-265 Vac
Display Type	Digital
Design	Smps
Series	LRS Series
Brand	Meanwell
Input Current	Standard Single Phase
Usage/Application	Industrial Automation

Reliable Performance for Industrial Applications

The LRS-50-15 is engineered for uninterrupted operation in demanding environments. With high-efficiency conversion, robust internal protections, and compliance to global safety standards, this compact power supply can withstand vibrations, surges, and humid conditions, making it ideal for factory automation, mechanical equipment, and electronic control panels.

Compact and Convenient Design

Featuring a lightweight (230g), enclosed metal case with chassis mounting, the LRS-50-15 is quick and straightforward to install using its screw terminal connectors. Thanks to its convection cooling method and wide temperature tolerance (-30C to +70C), space savings and placement flexibility are assured without compromising reliability.

FAQs of MEAN WELL LRS-50-15:

Q: How do I mount the MEAN WELL LRS-50-15 power supply in my application?

A: This unit is designed for chassis mounting and features screw terminal connectors for secure, convenient wiring, allowing you to easily integrate it into industrial cabinets, automation panels, or mechanical equipment.

Q: What occurs if the output current exceeds the rated 3.5A of the LRS-50-15?

A: The LRS-50-15 includes overload and short circuit protection. If the output current surpasses 3.5A, the power supply automatically limits current to protect both itself and connected devices, ensuring maximum safety.

Q: When is adjustment of the output voltage necessary and how is it performed?

A: Adjust the output voltage (within 13.5 to 16.5V) if your equipment requires a voltage different than the default 15V. Use the onboard potentiometer (V. Adj.) for precise tuning to meet your system specifications.

Q: Where can the LRS-50-15 be used effectively?

A: The LRS-50-15 is suited for industrial control systems, factory automation, mechanical devices, and other electrical equipment, thriving in environments with temperatures from -30C to +70C, and humidity up to 90% RH (non-condensing).

Q: What safety and regulatory standards does this power supply fulfill?

A: This model is approved under UL62368-1, EN62368-1, and IEC62368-1 standards, providing verified protections and reliability for industrial and commercial electrical applications.

Q: How does the LRS-50-15 benefit industrial applications?

A: Its high efficiency, compact form factor, wide input voltage range, and built-in EMI filtering combine to offer dependable performance, reduced space requirements, and seamless system integration, leading to reduced downtime and lower operational costs.
