Mornsun SMPS-LM150-20B12 150 Watt 12.5 Amp 12Vdc

Mornsun SMPS-LM150-20B12 150 Watt 12.5 Amp 12Vdc Price And Quantity

• Minimum Order Quantity 10 Piece
• Price 795 INR/Piece

• Isolation Voltage Input-Output: 3kVac, Input-GND: 1.5kVac, Output-GND: 0.5kVac
• Output Voltage 12Vdc
• Parallel Operation No
• Remote Sense No
• Input Frequency 47-63 Hz
• Dimension 159 x 97 x 38 mm
• Ripple and Noise 150mVp-p
• Adjustable Output Voltage Range 10.2-13.8Vdc
• Installation Type Chassis Mount
• Remote On/Off Control No
• MTBF >300,000 hours
• Hold-up Time 20ms (at full load, 230Vac input)

Mornsun SMPS-LM150-20B12 150 Watt 12.5 Amp 12Vdc Product Specifications

• Rated Power 150W
• Line Regulation 0.5%
• Output Type Single Output
• Weight 700g
• Phase Single Phase
• Efficiency Typical 88%
• Connector Type Screw Terminal
• Output Current 12.5A Ampere (amp)
• Rated Current 12.5A
• Working Temperature -30C to +70C
• Input Voltage 85-264VAC, 120-373VDC Volt (V)
• Operating Temperature -30C to +70C
• Power Supply AC-DC
• Output Frequency 47-63Hz
• Product Type SMPS
• Storage Temperature -40C to +85C
• Noise Level 150mVp-p
• Material Metal Enclosure
• Cooling Method Natural Air Cooling
• Features Compact size, High reliability, Low ripple and noise, High efficiency
• Voltage Protection Overvoltage, Short Circuit, Overload Protection
• Output Power 150 Watt
• Application Industrial Automation
• Current Range 0-12.5A
• Power Factor >0.5

• Isolation Voltage Input-Output: 3kVac, Input-GND: 1.5kVac, Output-GND: 0.5kVac
• Output Voltage 12Vdc
• Parallel Operation No
• Remote Sense No
• Input Frequency 47-63 Hz
• Dimension 159 x 97 x 38 mm
• Ripple and Noise 150mVp-p
• Adjustable Output Voltage Range 10.2-13.8Vdc
• Installation Type Chassis Mount
• Remote On/Off Control No
• MTBF >300,000 hours
• Hold-up Time 20ms (at full load, 230Vac input)

Mornsun SMPS-LM150-20B12 150 Watt 12.5 Amp 12Vdc Trade Information

• Supply Ability 5000 Piece Per Month
• Delivery Time 7 Days
• Main Domestic Market All India
